Handheld PDA

Handheld Terminal Data Collector Warehouse Inventory Management 1D Barcode Scanner 2d bar code reader pda

Handheld Terminal Data Collector Warehouse Inventory Management 1D Barcode Scanner 2d bar code reader pda

OS:Android 8.1 2G+16G
Display:5.5 inch IPS color display with resolution720*1440
Standard:WiFi,Bluetooth,4G,GPS,Camera
Option:1D/2D barcode,NFC
Product description: RL-H50 is an Android rugged Handheld Terminal PDA. high-performance, high-reliability industrial-grade handheld barcode data terminal based on the Android 8.1 operating system. It has strong and stabl
INQUIRY

Handheld Terminal Data Collector Warehouse Inventory Management 1D Barcode Scanner 2d bar code reader pda -Order Now

Specification
Model Number	RL-RH50
Performance Quad-core
CPU	Cortex-A53 64bit Quad-core 2.0GHz
RAM+ROM	2GB+16GB (Supports up to 3GB+32GB)
Expansion	Supports up to 128 GB Micro SD card
Operating System	Android 8.1
Performance OCTA core
CPU	Cortex-A53 64bit Quad-core 2.0GHz
RAM+ROM	2GB+16GB (Supports up to 3GB+32GB/4GB+64GB)
Expansion	Supports up to 128 GB Micro SD card
Operating System	Android 9.0
Data Communication
WLAN	Dual-band 2.4GHz /5GHz, Supporting IEEE 802 a/b/g/n/ac protocol
WWAN	2G：GSM（850/900/1800/1900MHz）
	3G：WCDMA（850/900/1900/2100MHz）
	4G：FDD:B1/B3/B4/B7/B8/B12/B20,TDD:B38/B39/B40/B41
Bluetooth	Support Bluetooth 2.0+EDR/3.0+HS/4.1+HS, transmission distance is 5-10m
Physical Characteristics
Dimensions 147.3mm×71.1mm×13.5mm
Weight <500g ((Depends on device function configuration）)
Display 5.5 inch IPS color display with resolution720*1440
TP Corning Gorilla glass, Supports multi-touch, Supported gloves and wet hands
Power Rechargeable polymer battery (3.8V 4200mAh) removable
Standby: over 350 hours
Continuous use: over 12 hours (depending on user environment)
Charging time: 3-4 hours (with standard adaptor and USB cable)
Fast charging:1.5H（Optional）
Expansion Slot PSAM x 2, Micro SIM card x 1 , TF card × 1
Interfaces Type-C USB x 1, OTG
Audio Speaker (mono), Microphone, Earpiece
Keypad Silicone button: Power button, Volume +/- button, Scan button × 2
Sensor Gravity sensor, Light sensor, Proximity sensor, Vibration motor
User Environment
Operating Temp.	-4°F to 122°F / -20°C to 50°C
Storage Temp.	-40°F to 158°F / -40°C to 70°C
Humidity	5%RH - 95%RH non condensing

Drop Specification	6 sides Supports 1.5 meters drops and 30 times to the concrete in the operating temperature

Rolling test	500×0.5m rolling for 6 sides
Protection Level	IP-66
Data Collection
Rear Camera	13MP HD camera, Support auto focus, Flash, Anti-shake, Macro shooting
Front Camera	2MP color camera
Barcode Scanning (Optional)
2D Linear scanner	Honeywell N3601/6603
2D Symbologies	PDF417,Micro PDF417,GS1 Composite, Aztec Code, Data Matrix, QR Code, Micro QR Code,Maxicode, Hanxin Code,etc.

NFC (Optional)
Frequency	13.56MHz
Protocol	Support ISO14443A/B, ISO15693
Range	2-5cm
Language/input method
Input	English, Pinyin, Five strokes, Handwriting input, Support soft keypad
Language	Language packs in Simplified Chinese, Traditional Chinese, English, Korean, Japanese, Malaysian,etc.
Accessories
Standard Adapter, Data cable, Protective film, Instruction manual
Optional Cradle, etc.
